9516 Outdoor Injection Epoxy Resin For Electric Bushings And Isolators

Ask Lasest Price
Brand Name :	wenyou
Model Number :	9516
Certification :	ISO.CE
Price :	2.35-2.8USD/KG
Payment Terms :	L/C, T/T
Supply Ability :	50000BARELS/MONTH

Add to Cart

Product Details
Company Profile

9516 Outdoor Injection Epoxy Resin For Electric Bushings And Isolators

SHANGHAI WEN YOU INDUSTRY CO. , LTD .

Outdoor Epoxy Resin

LE- 9516/LH-9516 Syetem

Version of 2019.12

No:2019129516

Epoxy resin

Hardener

Filler

Color paste

LE-9516

LH-9516

Silica

LC-

100pb w

100pbw

350-400pbw

3pbw

Formulation

A two component saturated epoxy resin system without premixed filler, liquid at room temperature. Performance

It is suitable for both APG injection process and vacuum casting process.

Excellent UV resistance, excellent thermal and thermal shock resistance, excellent environmental resistance and

excellent electromechanical performance.

Outdoor high-voltage electrical insulation parts such as: insulators, transformers

and other insulation products.

Application

Resin LE-9516 is a modified saturated epoxy resin system .

Physical and chemical indicators

Curing agent LH-9516 is a modified weathering anhydride curing agent.

Property	Unit	Standard	Property	Unit	Standard
Appearance	Visual	Transparent-yellow liquid	Appearance	Visual	Transparent-yellow liquid
Epoxy value	Eq/kg	4.0-4.5	viscosity at 25℃	mPa.s	150-400
viscosity at 25℃	mPa.s	500- 1500	Density at 25℃	g/cm3	1.17- 1.24
Density at 25℃	g/cm3	1.16- 1.20	VP	Pa	About 0.5
VP at 25℃	Pa	<0.01	Flash point	℃	About 140
Flash point	℃	About 135

Epoxy resin LE-9516, curing agent LH-9516 and a certain amount of filler can be mixed

according to the following curing process after fully mixing under vacuum conditions:

Process

Processing parameters	Automatic Pressure Gelation	Vacuum casting
Epoxy Resin/Hardener mixing temperature	40℃/1-2h	50-60℃/1- 1.5h
Feeding method	Pressure(0.5-5bar)	Vacuum (casting pot)
Mold temperature	130-150℃	105℃/4-6h
Gelation time	10-50mins	80℃/4h+100℃/2h+120℃/2h
Post-curing	130-140℃×6-10h	130-140℃×6-10h

Page1 of 2 9516 Specification Page1 of 2

LE-9516:LH-9516=100:100

Gel time

Temperature	Gel time
at 120℃	20-40mins
at 140℃	9-18mins
at 160℃	4-8mins

Mechanical and physical properties

Test system: Resin LE- 9516 / curing agent LH-9516 / silica flour=100/100/400 Curing conditions: 120 ° C × 4hours +

140 ° C × 8hours

Note: The following performance data are measured according to the national standard and are for user reference only.

The specific application data should be determined according to the actual conditions of the user.

Properties	Typical results	Properties	Typical results
Tg(DSC)	60-80℃	Thermal decomposition temperature	>320℃
tensile strength	60-80N/ mm2	Water absorption rate (23 ° C × 10 days)	0.10-0.20 %by wt.
Flexural strength	100- 130N/ mm2	Water absorption rate (100 ° C × 60 minutes)	0.08-0.15 %by wt.
Compressive strength	140- 190N/ mm2	Surface resistivity	1014 Ω
Impact strength	8- 16kJ/ m2	Volume resistivity	1015 Ω.cm
Curing shrinkage	0.8- 1.0%	Dielectric strength	31 kv/mm
Flame resistance (4mm)	HB level	Dielectric loss	0.02
Thermal conductivity	0.8-0.9W/mk

Storage

Storage of the components should be kept at 6-35℃ in tightly sealed and dry. Under these conditions, the shelf life should be correspond to the package labeled ( normally 12 months). After this date, the product may be re-analysis to confirm if it validate yet. Partial emptied containers should

be closed tightly immediately after use.

Package

Epoxy resin 20kg/pail or 220kg/pail or 1200kg/pail, Hardener 20kg/pail or 220kg/pail or 1200kg/pail.

First Aid

Contamination of eyes by resin, hardener of casting mix should be treated immediately by flushing with clean,running water for 10 to 15minutes, a doctor should then be consulted. Material smeared or splashed on the skin should be dabbed off, and the contaminated area then washed and treated with a cleaning cream. A doctor should be on the event of severe imitation of burns. Contaminated clothing should be changed immediately. Anyone taken ill after inhaling vapors should be moved out of doorsimmediately,in all case of doubt call for medical assistance.

Page 2 of 2 9516 Specification Page 2 of 2
