LE-8214F indoor electric epoxy resin for dry type electric power transformer casting

LE-8214F electric epoxy resin for dry type power transformer

Properties

Two-component epoxy resin system, liquid at room temperature, suitable for vacuum casting process

Lower curing shrinkage, dimensional stability of end product, excellent processing performance and high dielectric and mechanical properties.

Application

Medium and high voltage electrical insulation products

such as dry type transformers, 10-66kV current and voltage transformers etc.

Product Data

LE-8214F is a modified BPA type epoxy resin. LH-8214F is a modified carboxylic anhydride liquid Hardener

Epoxy resin LE-8214F and hardener LH-8214F with a certain quantity of filler can be processed by following conditions after fully mixed under vacuum conditions. Process condition

8214F Application process recommendation

1. Preparation of ingredients

1.1 The casting mold should be preheated in the oven at 100-110 ° C for more than 10 hours, and above 4000kva transformer coil shall be given a longer preheating time,

To ensure that the coil is completely dry and its temperature is not less than 80 ° C when installed.

1.2 The silica powder shall be sealed to normal temperature for more than 6 hours in an oven at 110-120 ° C.

2. Ingredients

2.1 Static mixture degassing

2.1.1 Premixing

Material A (epoxy) is based on weight ratio, resin: filler: color paste 100:(125-color paste amount):proper amount, and mixed separately after adding resin, filler and color paste,

The temperature is 65-70 ℃, stirring and degassing for no less than 2 hours, and 100 < p < 200pa.

Material B (curing agent) is based on the weight ratio, curing agent: filler 100:125, mixed separately, temperature is 65-70 ℃, stirring and degassing are not less than 2 hours, 100 < p < 200pa.

2.1.2 Final mixing

Then the components A and B are finally mixed, the accelerator agent is not needed, and put material A and B are mixed in the proportion of 100:100 into (or vacuum suction) final mixing tank, and in order to stir well, we advise put the resin and hardener at same or alternate time

2.1.3 Start stirring after feeding,make sure the the spiral lifter can lift the mixture onto the umbrella degassing hood at its rotate speed

2.1.4 After stirring for 15 minutes, start the vacuum pump for degassing. The vacuum degree shall not be less than 300pa

2.1.5 The mixing degassing time is about 15-30 minutes, and the degassing is completed when there is no bubble on the umbrella surface

3. Casting

3.1 Set the casting tank temperature at 80-85 ℃, preheating shall start 4-5 hours before batching, and to ensure that the temperature of the mold during installation is not less than 80 ° C

3.2 After batching, the dried and preheated mold is pushed into the casting tank for vacuum treatment

3.3 The space temperature of the casting tank is 80-85 ° C, the vacuum degree is not less than 300pa, and the vacuum treatment time is not less than 2 hours

3.4 , The feeding should not be too fast during casting. It can be stopped for 10-15 minutes, and the vacuum can be continued for 20-30 minutes after the material is full. If possible, it can be pressurized by 0.2-0.3mpa after vacuum treatment

3.5 The final mixing casting shall be completed within 90 minutes. Please strictly control the temperature and time to prevent tank solidification. The excess single component resin and curing agent can be stored for several days.
